Short Description:
This anti-scald valve is designed to automatically regulate water temperature in shower and eyewash systems. It ensures that the water does not exceed safe temperatures, providing protection against scalding.
Features:
- Temperature activated valve
- Automatically bleeds water to prevent scalding
- Protected with anti-corrosive Polyamide 11 coating
- Good resistance to acids, bases, seawater, and oils
Specifications
- Connection: ½? Female
- Water inlet pressure: Recommended 2 bar with a maximum of 4 bar (Operation not affected by pressure variations) - please notify us prior to ordering if your water pressure is below 1.5 bar.
- Water supply temperature: 80°C maximum
- Maximum opening temperature: 40.5°C
- Fully closed temperature: 35°C
Benefits:
- Enhances safety by preventing scalding
- Durable coating increases longevity
- Easy installation with standard connection
Use Cases:
- Shower systems
- Eyewash stations
FAQ:
Q: What is the maximum water supply temperature?
A: The maximum water supply temperature is 80°C.
Q: What is the recommended water inlet pressure?
A: The recommended water inlet pressure is 2 bar, with a maximum of 4 bar.
Short Description:
This anti-scald valve is designed to automatically regulate water temperature in shower and eyewash systems. It ensures that the water does not exceed safe temperatures, providing protection against scalding.
Features:
- Temperature activated valve
- Automatically bleeds water to prevent scalding
- Protected with anti-corrosive Polyamide 11 coating
- Good resistance to acids, bases, seawater, and oils
Specifications
- Connection: ½? Female
- Water inlet pressure: Recommended 2 bar with a maximum of 4 bar (Operation not affected by pressure variations) - please notify us prior to ordering if your water pressure is below 1.5 bar.
- Water supply temperature: 80°C maximum
- Maximum opening temperature: 40.5°C
- Fully closed temperature: 35°C
Benefits:
- Enhances safety by preventing scalding
- Durable coating increases longevity
- Easy installation with standard connection
Use Cases:
- Shower systems
- Eyewash stations
FAQ:
Q: What is the maximum water supply temperature?
A: The maximum water supply temperature is 80°C.
Q: What is the recommended water inlet pressure?
A: The recommended water inlet pressure is 2 bar, with a maximum of 4 bar.
