Short Description:
This pedestal mounted emergency eye wash is designed for quick and effective eye irrigation in industrial settings. It features dual control activation for ease of use in emergencies.
Features:
- Galvanised steel pipe work with anti-corrosive polyamide 11 coating
- High visibility yellow plastic coating for good resistance to acids, bases, seawater, and oils
- Eye wash assembly and bowl made from ABS reinforced plastic
- Two high flow, aerated low pressure outlets with automatic opening dust covers
- Activation by hand paddle or foot treadle
- Meets internationally recognised standards ANSI Z358.1
Specifications
- Water inlet: ½? BSP
- Water inlet pressure: Recommended 2 bar with a maximum of 8 bar - please notify us prior to ordering if your water pressure is below 1.5 bar
- Eyewash flow rate: 22lpm
- Eyewash operation: Push paddle & foot treadle
- Eyewash valve: Full bore ½?
- Waste: 1¼? BSP
- Total weight: 7.5kg
- Dimensions: 80 x 27 x 13cm
Benefits:
- Durable construction ensures long-lasting performance
- High visibility design enhances safety in emergency situations
- Quick activation allows for immediate response to eye injuries
Use Cases:
- Manufacturing facilities
- Chemical processing plants
- Laboratories
FAQ:
Q: What is the flow rate of the eye wash?
A: The eyewash flow rate is 22 litres per minute.
Q: How is the eye wash activated?
A: The eye wash can be activated by either pushing the hand paddle or standing on the foot treadle.
Q: What is the recommended water inlet pressure?
A: The recommended water inlet pressure is 2 bar, with a maximum of 8 bar.
Short Description:
This pedestal mounted emergency eye wash is designed for quick and effective eye irrigation in industrial settings. It features dual control activation for ease of use in emergencies.
Features:
- Galvanised steel pipe work with anti-corrosive polyamide 11 coating
- High visibility yellow plastic coating for good resistance to acids, bases, seawater, and oils
- Eye wash assembly and bowl made from ABS reinforced plastic
- Two high flow, aerated low pressure outlets with automatic opening dust covers
- Activation by hand paddle or foot treadle
- Meets internationally recognised standards ANSI Z358.1
Specifications
- Water inlet: ½? BSP
- Water inlet pressure: Recommended 2 bar with a maximum of 8 bar - please notify us prior to ordering if your water pressure is below 1.5 bar
- Eyewash flow rate: 22lpm
- Eyewash operation: Push paddle & foot treadle
- Eyewash valve: Full bore ½?
- Waste: 1¼? BSP
- Total weight: 7.5kg
- Dimensions: 80 x 27 x 13cm
Benefits:
- Durable construction ensures long-lasting performance
- High visibility design enhances safety in emergency situations
- Quick activation allows for immediate response to eye injuries
Use Cases:
- Manufacturing facilities
- Chemical processing plants
- Laboratories
FAQ:
Q: What is the flow rate of the eye wash?
A: The eyewash flow rate is 22 litres per minute.
Q: How is the eye wash activated?
A: The eye wash can be activated by either pushing the hand paddle or standing on the foot treadle.
Q: What is the recommended water inlet pressure?
A: The recommended water inlet pressure is 2 bar, with a maximum of 8 bar.
