This polyethylene environmental cabinet is designed for the safe storage of corrosive and aggressive liquids. Ideal for industrial and laboratory use, it features multiple spill pallets and a sealed sump.
Specifications
| Technical data | Details |
|---|---|
| Cabinet type | High cabinet |
| Media to be stored | Corrosive liquids |
| Features | 3 slide-out spill pallets, 1 grid, stainless steel |
| Number of storage levels | 4 |
| Door version | Hinged door |
| Door hinge | both sides |
| Door design | 2 wing doors |
| Door colour | Yellow |
| Body colour | Grey |
| Material | Plastic |
| External dimensions W x D x H [mm] | 1225 x 640 x 1990 |
| Internal dimensions W x D x H [mm] | 1130 x 410 x 1750 |
| Weight [kg] | 96,5 |
| Spill pallet load capacity [kg] | 50 |
| Shelf load capacity [kg] | 50 |
| Spill pallet containment volume [l] | 11 |
| Floor spill pallet containment volume [l] | 75 |
| Features | With spill trays or slide-out spill pallets |
Key Features
- For the safe storage of water-polluting and aggressive liquids
- Made from highly resistant plastic (polyethylene)
- Connection point for extraction fan
- Operational colour scheme: grey body, doors in signal yellow, with 2 keys
- Ready for use - set up, store, done
- Liquids according to the media list 40-1.1 from the DIBt with a reduction ratio A2≤1.1 as well as liquids in the following substance groups may be stored: Aqueous solutions of organic acids up to 10% Mineral acids up to 20% Inorganic alkalis as well as alkali hydrolysing salts in aqueous solution (pH > 8), except for ammonia solutions and oxidising solutions of salts (e.g. hypochlorite) Solutions of inorganic non-oxidising salts with a pH value between 6 and 8
- 3 slide-out spill pallets, 1 grid, stainless steel
- Height distance between 2 grids/slide-out spill pallets with 8 storage levels: 194mm Height distance between 2 grids/slide-out spill pallets with 4 storage levels: 418mm
- Certified quality - General Construction Approval Z-40.22-543
- Sealed sump in the bottom of the cabinet
- DIBt
Benefits
- Safe storage for corrosive and aggressive liquids
- Easy access with slide-out spill pallets
- Sealed sump prevents leaks and spills
Use Cases
- Industrial storage
- Laboratories
- Chemical handling
FAQ
Q: What liquids can be stored in this cabinet?
A: Aqueous solutions of organic acids up to 10%, mineral acids up to 20%, and inorganic alkalis.
Q: Is the cabinet ready for immediate use?
A: Yes, it is ready for use upon delivery.
This polyethylene environmental cabinet is designed for the safe storage of corrosive and aggressive liquids. Ideal for industrial and laboratory use, it features multiple spill pallets and a sealed sump.
Specifications
| Technical data | Details |
|---|---|
| Cabinet type | High cabinet |
| Media to be stored | Corrosive liquids |
| Features | 3 slide-out spill pallets, 1 grid, stainless steel |
| Number of storage levels | 4 |
| Door version | Hinged door |
| Door hinge | both sides |
| Door design | 2 wing doors |
| Door colour | Yellow |
| Body colour | Grey |
| Material | Plastic |
| External dimensions W x D x H [mm] | 1225 x 640 x 1990 |
| Internal dimensions W x D x H [mm] | 1130 x 410 x 1750 |
| Weight [kg] | 96,5 |
| Spill pallet load capacity [kg] | 50 |
| Shelf load capacity [kg] | 50 |
| Spill pallet containment volume [l] | 11 |
| Floor spill pallet containment volume [l] | 75 |
| Features | With spill trays or slide-out spill pallets |
Key Features
- For the safe storage of water-polluting and aggressive liquids
- Made from highly resistant plastic (polyethylene)
- Connection point for extraction fan
- Operational colour scheme: grey body, doors in signal yellow, with 2 keys
- Ready for use - set up, store, done
- Liquids according to the media list 40-1.1 from the DIBt with a reduction ratio A2≤1.1 as well as liquids in the following substance groups may be stored: Aqueous solutions of organic acids up to 10% Mineral acids up to 20% Inorganic alkalis as well as alkali hydrolysing salts in aqueous solution (pH > 8), except for ammonia solutions and oxidising solutions of salts (e.g. hypochlorite) Solutions of inorganic non-oxidising salts with a pH value between 6 and 8
- 3 slide-out spill pallets, 1 grid, stainless steel
- Height distance between 2 grids/slide-out spill pallets with 8 storage levels: 194mm Height distance between 2 grids/slide-out spill pallets with 4 storage levels: 418mm
- Certified quality - General Construction Approval Z-40.22-543
- Sealed sump in the bottom of the cabinet
- DIBt
Benefits
- Safe storage for corrosive and aggressive liquids
- Easy access with slide-out spill pallets
- Sealed sump prevents leaks and spills
Use Cases
- Industrial storage
- Laboratories
- Chemical handling
FAQ
Q: What liquids can be stored in this cabinet?
A: Aqueous solutions of organic acids up to 10%, mineral acids up to 20%, and inorganic alkalis.
Q: Is the cabinet ready for immediate use?
A: Yes, it is ready for use upon delivery.
